Angle Measurement 1", 2", 3",  5", 7"

Distance Measurement

(Single Prism) 1.3 to 4,000m (4.3 to 13,120ft.) / Under good conditions*6: 5,000m (16,400ft.)*
Good conditions: No haze, visibility about 40km (25 miles), overcast, no scintillation.

Distance Measurement

(Reflectorless) 0.3 to 500m (1.0 to 1,640ft.)*
Good conditions: No haze, visibility about 40km (25 miles), overcast, no scintillation.

Accuracy (Single Prism) (2 + 2ppm x D) mm

Accuracy (Reflectorless) (3 + 2ppm x D) mm*
Measuring range:0.3 to 200m

Measuring Time Fine: 0.9s (initial 1.7s), Rapid: 0.7s (initial 1.4s), Tracking: 0.3s (initial 1.4s)

Tilt Compensation Dual Axis, Compensation Range +/- 6'

Wireless Communication Bluetooth Class 1 - 300m (980ft)
No obstacles, few vehicles or sources of radio emissions/interference in the near vicinity of the instrument, no rain.

Display / Keyboard Graphic LCD, 192 x 80 dots, backlight, contrast adjustment / Alphanumeric keyboard / 25 keys with backlight

Data storage Approx. 10,000 points* Optional USB flash memory supported for additional storage

Dust/Water Protection IP66

Operating Temperature -20 to +50ºC (-4 to +122ºF)

Size (dual face model) W191 x D181 x H348mm (W7.5 x D7.1 x H13.7in.)

Weight (battery & tribrach) Approx. 5.6kg (12.3 lb.)

Operating Time Approx. 36 hours (single distance measurement every 30 seconds)
