Murah Total Station Topcon GTS 255N Promo Di 081210895144
Harga :
Rp. 55.000.000 / Set
Pembelian Minimal :
1 Set
Pembelian Maksimal :
4 Set
Pengiriman :
3 hari sejak pembayaran
Update Terakhir :
10-08-2014 09:37
Dapatkan Spesifikasi Harga
Murah Total Station Topcon GTS 255N Promo Di 081210895144 Produk Terbaik dari
MISI Penjualan alat survey dan pemetaan
Detail Produk
| Specifications |
| Telescope |
| Length |
150 Millimeters |
| Objective Lens Diameter |
45mm (EDM:50mm) |
| Magnification |
30x |
| Image |
Erect |
| Field of View |
1°30 |
| Resolve Power |
3 " |
| Min. Focus Distance |
1.3 meters |
| Measurement Range |
| 1 Prism |
6560 ft, 2000 meters |
| 3 Prism |
8856 ft, 2700 meters |
| Measuring Accuracy |
| Prism Mode |
±(2mm + 2ppm x D)m.s.e. fine, N/A |
| Measurement Time |
1mm: 1.2sec. (Initial 4sec.) fine, 0.2sec. (Initial 3sec.) coarse, N/A |
| Angle Measurement |
| Method |
Absolute Reading |
| Detection |
2 horizontal, 1 vertical |
| Minimum reading |
5”/1”, 1/5 mgon |
| Tilt Correction |
| Type |
Automatic Vertical and Horizontal compensator |
| Method |
Liquid surface reflective profile sensor reading type |
| Compensating Range |
±3' |
| Correction Unit |
1 arc sec, N/A |
| Computer Unit |
| Display |
2 screen, dot matrix graphic LCD display |
| Power |
| Approximate battery life |
9 hours including distance measurement , 40 Angle measurement only |
| Durability |
| Protection against water and dust |
IP54 |
| Temperature |
-20 to 50 degrees C (-4 to 122 degree F) |
| Weight |
Instrument 4.9KG (10.8lb) |
